F5 1600-6
KXITE
Parameters | DHF5 1600-6 | |
Max unwinding diameter | 1524mm | |
Max rewinding diameter | 1524mm | |
Max paper width | 1620mm | |
Max printing width | 1600mm | |
Plate repeat printing length | 520-1900mm
| |
Register precision | ±0.10mm | |
Plate thickness+ tape thickness | 1.7mm+0.5mm | |
Printing substrate | Paper: 100-350 gsm | Thickness：0.1mm-0.4mm |
Machine mechanical speed | 260m/min | |
Max printing speed | 240m/min | Speed may be impacted by but not limited to factors like: Substrate property Ink and additives property Printing plate and double side adhesive tape property Printing quality requirement |
Dryer type | Hot air | Electric heating (standard) or steam heating (optional) |
Ink | Water based ink or solvent ink | |
Machine layout | The unwinding unit is on the left-hand side when the operator faces the machine | The left-hand side or the right-hand side can be choiced according to the workshop layout |
Machine color | White with red (recommended) or blue |
1.
1. Main advantages:
l Non-stop Unwinder and Rewinder which improve work efficiency
l Enclosed chamber inking system with Double-ink pump which more convenient and fast cleaning
l Enclosed Drying system with high-pressure circulation hot air which can set the temperate It can greatly improve work efficiency.
l Pre-registration system the paper does not move, to achieve plate registration pre-positioning, which can reduce the waste of materials in registration.
l Inline printing quality inspection system(optional)
l Intelligent control system：
With real-time detection and computer automatic comparison of print quality, real-time alarm and record function can avoid defects. Intelligent control system: order preservation function (printing rules store/one-key call, printing pressure store/one-key call, printing, tension store/one-key call, pre-registration, vertical and horizontal vision automatic registration system, high-speed operation pressure adaptive system, closed-loop tension control, other functions) , automatic stop when broken paper, automatic alarm deceleration and stop, automatic stop when order is completed, automatic count, multi-point speed regulation, self-check and fault recording function, remote diagnosis function, self-service equipment maintenance function and so on, the use of equipment to let you worry-free
